LED cabinet
Cabinet size(WxHxD)	960*960mm
Cabinet resolution	96dots×96dots
Cabinet pixels	9216dots
Driving method	1/2scan
Weight(kg/pcs)	30kg/pcs
Material	waterproof die casting cabinet
Included	1. E-energy/Meanwell Power supplies
	2. Fans
	3.MBI5124IC
	4. Mounting/locking plates between cabinets
	5. Inter-connecting cables & ribbons (both power and signal)

Working voltage	110/220V 50Hz-60Hz
Average power consumption	300W/m²
Max power consumption	800 W/m²
Brightness	>6000 nits (cd/m²)
Gray level	65,536 levels
Refresh rate	> 1920 Hz
Viewing angle	150º/150º
best Viewing distance	10m-100m
Frame rate	> 60 frames/sec
Defects rate	≤0.00001
Available color palette	4.4 Trillion colors (RGB 14 bit control)
MTBF	> 10,000hours
Life-span	> 100,000 hours
Protective Grade	IP65
Working temperature	-20℃ ~ +60℃
Operating humidity	10%~90%
Control system
Software	Nova/linsn/mooncell/colorlight
PC system	Windows (2000/XP/Vista/win7)
Control distance	Within 100m adopts UTP netcable; 100m~500m adopts Multi-mode Fiber; 500m~10000m adopts Single-mode Fiber (distance between PC and screp ledn)
Control method	Maincontroller + off-line control card
Display format	All format ( AVI.MPEG.VOB.RM ect)
Brightness control	Manual or Automatic Control
Video input	All video signal ( S-VHS, DVD, TV, Satellite, Color- Camera, PC-VGA)
